TREE SHEAR

JAK-200 Tree Shear

JAK-250K Tree Shear

JAK-200T Tree Shear

JAK-20X MULTI

GRAPPLE


JAK-200K Tree Shear

JAK-250R Tree Shear

JAK-200TC Tree Shear

JAK-200R Tree Shear

JAK-300 Tree Shear

JAK-220T Tree Shear

JAK-250 Tree Shear

JAK-300R Tree Shear

JAK-220TC Tree Shear

JAK-200 1
JAK-200 with support
JAK-200 2

JAK-200 Tree Shear

JAK-200 is the powerhouse of smaller excavators


JAK-200 is the master of tree shears for smaller scale excavators, which, despite its compact size, is a real powerhouse. JAK-200 is great for clearing of roadsides and field sides, for example.


JAK-200 is the master of tree shears for smaller scale excavators, which, despite its compact size, is a real powerhouse. JAK-200 is great for clearing of roadsides and field sides, for example.


Developed for heavy use, JAK-200 cuts the wood to be harvested neatly and precisely at the desired point from ground level. With this agile and strong tree shear, energy wood can be easily cleared up to tree trunks up to 20 cm thick, which is why its possibilities of use are rather versatile. Many of our customers have also harnessed JAK-200 for the care of trees in gardens and parks, for example.


With the JAK-200’s wide 600 mm opening, it is also easy to cut several small trees at once. The JAK-200’s design-protected structure takes an unmistakable grip on the desired wood material, allowing the pressed wood to be neatly cut. If necessary, the cutting blade can be removed, in which case the tree shear acts as a wood grapple.


FEATURES

  • Two-year warranty
  • Made in Finland
  • For versatile clearing
  • Removable blade
  • Agile and durable


ACCESSORIES

  • Felling support

  • Quick valve

JAK-200K 1
JAK-200K 2
JAK-200K 3
JAK-200K 5
JAK-200K 4
JAK-200K 6

JAK-200K Tree Shear

JAK-200K turns a tractor into a clearing machine


JAK-200K is a tree shear compatible with the timber loader of standard tractors weighing 3 to 10 tons, with which various thinning and clearing works are effortlessly successful. Developed for heavy use, JAK-200K cuts the wood to be harvested neatly and precisely at the desired point from ground level.


A tractor equipped with a timber loader and JAK-200K tree shear makes clearing energy wood easy, fast and effortless. JAK-200K cuts trees efficiently up to 20 cm thick trunks, which makes it very versatile. Many use this model in tractors, for example, for clearing the roadsides and field sides. Thanks to its agile and fast movement, trees and shrubs can be cleared quickly even from a larger area.


With the JAK-200K’s wide 600 mm opening, several smaller trees can also be grabbed and cut at once if necessary. Reliable and easy-to-use JAK-200K makes wood handling effortless. If necessary, the cutting blade can be removed, in which case the tree shear acts as a normal wood grapple.


FEATURES

  • Warranty 2 years
  • CE approved
  • Made in Finland
  • Operation with one hydraulics
  • Removable blade
  • Powerful and durable
Skärmavbild 2022-03-18 kl. 08.25.24
Skärmavbild 2022-03-18 kl. 08.34.35
Skärmavbild 2022-03-18 kl. 08.34.43
Skärmavbild 2022-03-18 kl. 08.34.53

JAK-200R Tree Shear

JAK-200R makes a small machine a versatile clearer


The JAK-200R is the smallest model in the R-Series for smaller size wheel loaders and telehandlers. The JAK-200R is ideal for fast and efficient clearing of street curbs and park areas, for example. By replacing the rear end, it is also possible to harness the JAK-200R for use in small excavators, for example.


Developed for heavy-duty use, the JAK-200R cuts the wood to be harvested neatly and precisely from the desired point. With this agile and strong tree shear, clearing of wood is easy even up to 20 cm (7,8 in) thick tree trunks. The JAK-200R’s wide opening of 600 mm (23,6 in) makes it easy to catch and cut several small trees at once.


The design-protected structure takes an unmistakable grip on the wood. Thanks to its agile and fast movement, trees and shrubs can be cleared quickly even from a larger area. If necessary, the cutting blade can also be removed, in which case the tree shear acts as a normal wood grapple.


FEATURES

  • Warranty 2 years
  • CE approved
  • Made in Finland
  • Removable blade
  • Operation with two cylinders
  • Made by Hardox Steel
  • Agile and efficient


ACCESSORIES

  • Felling support

  • Quick valve

JAK-250 1
JAK-250 collector 2
JAK-250 2
JAK-250 collector 1
JAK-250 with collector
JAK-250 with support

JAK-250 Tree Shear

Multi-purpose JAK-250 is suitable from roadsides to carr forests


JAK-250 is our efficient and multi-purpose tree shear that is best suited for use with 5 to 12 ton excavators. The power of this popular tree shear is superior in its size range, and it is versatile for clearing small twigs and felling even larger trees.


The structure with two cylinders cuts the trees efficiently and precisely up to a thickness of 25 cm. The jaws and high profile of the JAK-250 tree shear take a firm and unmistakable grip on the wood. With the JAK-250’s wide 690 mm opening, it is also easy to cut several trees at once.


The firmly pressed wood is cut precisely and neatly thanks to a cutting blade shaped for the purpose, after which the wood material firmly attached to the grapple can be lifted to the desired location. If necessary, the cutting blade can be removed, in which case the tree shear acts as a wood grapple.


FEATURES

  • Two-year warranty
  • Agile and durable
  • CE approved
  • Made in Finland
  • For clearing and thinning
  • For 5 to 12 ton excavators


ACCESSORIES

  • Collector

  • Rotator

  • Quick valve

  • Felling support
JAK-250K 2
JAK-250K 1
JAK-250K 3
JAK-250K 6
JAK-250K 4
JAK-250K 5

JAK-250K Tree Shear

JAK-250K takes work productivity to a new level


JAK-250K is an efficient, professional energy wood tree shear for use in various forest machines as well as large tractors. Developed for heavy use, JAK-250K is a true power pack with which various thinning and clearing work can be done accurately and efficiently.


The design-protected design of JAK-250K tree shear with two cylinders cuts the trees exactly where you want. In the firm hold of the grapple, the wood material is neatly cut up to a thickness of 25 cm.


The strong jaws and high profile of the tree shear take a firm and unmistakable grip on the wood, making wood handling easy and safe. With the JAK-250K’s wide 690 mm opening, it is also easy to cut several trees at once.


The JAK-250K is powered by one double-acting hydraulics and can be installed as such to replace a standard timber grapple. If necessary, the cutting blade can be removed, in which case the tree shear acts as a wood grapple.


FEATURES

  • CE approved
  • Made in Finland
  • Operation with one hydraulics
  • Removable blade
  • Powerful and durable
  • Two-year warranty
Skärmavbild 2022-03-18 kl. 08.36.46
Skärmavbild 2022-03-18 kl. 08.34.35
Skärmavbild 2022-03-18 kl. 08.34.43
Skärmavbild 2022-03-18 kl. 08.34.53

JAK-250R Tree Shear

JAK-250R is a multi-purpose and efficient energy wood feller


The JAK-250R is designed for use with 3 to 6 ton (6600-13200 lbs) wheel loaders and telehandlers with a maximum lifting capacity of at least 900 kg (1984 lbs). By changing the rear part to be connected to the grapple, it is also possible to harness the JAK-250R for use in excavators, for example.


The structure with two cylinders cuts the trees efficiently and precisely up to a thickness of 25 cm (9,8 in). The jaws and high profile of the JAK-250R tree shear take a firm and unmistakable grip on the wood. With the JAK-250R’s wide 690 mm (27 in) opening, it is also easy to cut several trees at once.


The firmly pressed wood is cut precisely and neatly thanks to a cutting blade shaped for the purpose, after which the wood material firmly attached to the grapple can be lifted to the desired location.


If necessary, the cutting blade can be removed, in which case the tree shear acts as a wood grapple.


FEATURES

  •  Warranty 2 years

  •  CE approved

  •  Made in Finland

  •  Removable blade

  •  Operation with two cylinders

  • Made by Hardox Steel

  • Agile and efficient


ACCESSORIES

  • Collector

  • Rotator

  • Quick valve

JAK-300 1
JAK-300 2
JAK-300 collector 1
JAK-300 collector 2
JAK-300 with collector
JAK-300 with support

JAK-300 Tree Shear

JAK-300 is a true heavy-duty tree shear


JAK-300 is our most robust tree shear for excavators. It is designed for use on excavators weighing more than 12 tons. Due to its size, JAK-300 is ideal for felling larger trees in particular, but it is also ideal for clearing smaller crops.


Designed for use in large scale excavators, JAK-300 cuts the wood to be harvested neatly and precisely at the desired point from ground level. However, the efficiency of this tree shear is best noticed when faced with something more challenging than usual. Namely, JAK-300 also cuts larger trees effortlessly up to a thickness of 30 cm.


The jaws of the JAK-300 take an unmistakable grip on any wood. The wood that is firmly pressed by the shear is neatly cut thanks to the cutting blade. With the wide opening of the shear, several trees can also be cut at once, and the cutting force of the shear does not clot even with high mass. The high profile of JAK-300 ensures a firm grip on the wood during handling.

If necessary, the cutting blade can also be removed, in which case the tree shear acts as a wood grapple.


FEATURES

  • CE approved
  • Made in Finland
  • Two-year warranty
  • Removable blade
  • Powerful and durable
  • High profile


ACCESSORIES

  • Collector

  • Tilter

  • Rotator

  • Quick valve

  • Felling support

Skärmavbild 2022-03-18 kl. 08.42.15
Skärmavbild 2022-03-18 kl. 08.44.50
Skärmavbild 2022-03-18 kl. 08.44.56
Skärmavbild 2022-03-18 kl. 08.45.03
Skärmavbild 2022-03-18 kl. 08.44.42

JAK-300R Tree Shear

JAK-300R is a multi-purpose and efficient energy wood feller


The JAK-300R is designed for use with 6 to 21-ton kg (13227-46297 lbs) wheel loaders and telehandlers with a maximum lifting capacity of at least 1300 kg (2866 lbs) or more at their maximum reach. By changing the rear part to be connected to the grapple, it is also possible to harness the JAK-300R for use in excavators, for example.


The jaws of the JAK-300R take an unfailing grip on the wood. With the wide opening of the grapple, several trees can also be cut at once, and the force of the grapple does not coagulate even with a large mass. Due to its large size, the JAK-300R easily cuts a tree’s diameter up to 30cm (11,8 in) thick. At the same time, it is also ideal for felling into smaller stands, as its handling is precise and effortless.


The wood that has been firmly pressed by the grapple is neatly cut thanks to the grapple cutting blade. If necessary, the cutting blade located below the JAK-300R can also be removed, in which case the energy grapple acts as a normal wood grapple.


FEATURES

  • CE approved

  • Made in Finland

  • Two-year warranty

  • Removable blade

  • Many optional accessories

  • Possible to harness for use in other machines

  • Powerful and durable

  • High profile


ACCESSORIES

  • Collector

  • Rotator

  • Quick valve

  • Felling support

jak-200t-tree-shear
jak-200t-tree-shear-2
jak-200t-tree-shear-3
jak-200t-tree-shear-4
jak-200t-tree-shear-5
jak-200t-tree-shear-6
model-200t-and-200tc-fitting-options

JAK-200T Tree Shear

JAK-200T is the powerhouse of smaller forest cranes


The 200T multifunction tree shear can delimb, cut, and load easily, thanks to its agile and versatile movements. This 200T model is made for harvesting energy wood, clean up field sides and roadside areas, and different kinds of environmental works. The even bigger area is cleared quickly.


Before cutting, a standing tree can be delimbed by lifting with a crane. Delimbing blades cut branches of. After delimbing jaws take tight hold of the trunk and the hydraulic cutting blades cut the tree neatly and efficiently. After cutting the top of the tree stay still vertical position if wanted and it is an easy to move to the loading area or fell tree direct to the trailer.


Base machines: small harvesters, small forwarders, example Alstor, Kinetic, Usewood, Logbullet, etc, forest trailers with under 6,5m (21,3 ft) crane and small excavators 1,5 – 3t (3306-6613 lbs).



FEATUERS

  • No need for extra hydraulic or electric
  • No hoses or electrical wires to restrict grapple rotator
  • Easy and fast connecting
  • Cutting, loading, and delimbing the tree
  •  Guillotine and tilt-unit is possible to lock in the loading position
  • Also works as a loading grapple
  • Made with Hardox steel
jak-200tc-tree-shear
jak-200tc-tree-shear-2
jak-200tc-tree-shear-3
jak-200tc-tree-shear-4
jak-200tc-tree-shear-5
jak-200tc-tree-shear-6
model-200t-and-200tc-fitting-options

JAK-200TC Tree Shear

The JAK-200TC is an agile and lightweight tree shear that cuts, prunes, and loads trees. Equipped with a build-in collector, 200TC can grab several trees at the same time, which allows the tree shear to be used again immediately without unnecessary stops.

This 200TC model is made for harvesting energy wood, clean up field sides and roadside areas, and different kinds of environmental works. The even bigger area is cleared quickly. Smaller trees are possible to take so many than cutting capacity to give up. Just cut the first one and open and after that take the next one and next one etc. after the cutting capacity is full, just put the whole bush to the loading area or fall down direct to the trailer.

Before cutting, a standing tree can be delimbed by lifting with a crane. Delimbing blades cut branches off. After delimbing jaws take tight hold of the trunk and the hydraulic cutting blades cut the tree neatly and efficiently. After cutting the top of the tree stay still vertical position if wanted and it is easy to move to the loading area or fell tree direct to the trailer.

Base machines: small harvesters, small forwarders, example Alstor, Kinetic, Usewood, Logbullet, etc, forest trailers with under 6,5m (21,3 ft) crane and small excavators 1,5 – 3t (3306 – 6613 lbs).


FEATURES

  •  No need for extra hydraulic or electric

  • No hoses or electrical wires to restrict grapple rotator

  • Easy and fast connecting

  • Cutting, loading, delimbing the tree

  • Collector boosts productivity

  • Guillotine and tilt-unit is possible to lock in the loading position

  •  Also works as a loading grapple

  •  Made with Hardox steel

jak-220t-1
jak-220t-2
jak-220t-3
jak-220t-4
jak-220t-5
model-220t-and-220tc-fitting-options-2
model-220t-and-220tc-fitting-options

JAK-220T Tree Shear

JAK-220T prunes and cuts


220T is intended for use on over 6,5-meter (21,3 ft) cranes. Its cutting force is 1,7 times higher, thanks for the pressure booster. The 220T Multifunction tree shear can delimb, cut, and load easily because of its agile and versatile movements. This 220T model is made for harvesting energy wood, clean up field sides and roadside areas, and different kinds of environmental works. The even bigger area is cleared quickly.

Before cutting, a standing tree can be delimbed by lifting with a crane. Delimbing blades cut branches off. After delimbing jaws take tight hold of the trunk and the hydraulic cutting blades cut the tree neatly and efficiently. After cutting the top of the tree stay still vertical position if needed and it is easy to move to the loading area or fell tree direct to the trailer.

Base machines: small/medium size harvesters, small/medium size forwarders and, Tractors and forest trailers with over 6,5m (21,3 ft) crane and small excavators 3 – 6 ton kg (6613 – 16075 lbs).



FEATUERS

  • No need for extra hydraulic or electric

  • No hoses or electric wires to restrict grapple rotator

  • Easy and fast connecting

  • Cutting, loading, and delimbing the tree

  • Guillotine and tilt-unit is possible to lock for loading

  •  Also works as a loading grapple

  • Made with Hardox steel

jak-220tc-tree-shear
jak-220tc-tree-shear-2
jak-220tc-tree-shear-3
jak-220tc-tree-shear-4
jak-220tc-tree-shear-5
jak-220tc-tree-shear-6
model-220t-and-220tc-fitting-options-2
model-220t-and-220tc-fitting-options

JAK-220TC Tree Shear

220TC tree shear with collector makes tree clearing efficient


The 220TC multifunction tree shear is equipped collector/accumulation unit and it makes smaller trees harvesting about twice efficient. Even this model is equipped with a collector it can delimb, cut, and load easily, thanks to its agile and versatile movements. Its cutting force is 1,7 times higher, thanks for the pressure booster. This 220TC model is made for harvesting energy wood, clean up field sides and roadside areas, and different kinds of environmental works. The even bigger area is cleared quickly.

Smaller trees are possible to take so many than cutting capacity to give up. Just cut the first one and open and after that take the next one and next one etc. after the cutting capacity is full, just put the whole bush to the loading area or fall down direct to the trailer.

Even this 220 TC model is equipped with collector delimbing is possible anyhow. Before cutting, a standing tree can be delimbed by lifting with a crane. delimbing blades cut branches off. After delimbing jaws take tight hold of the trunk and the hydraulic cutting blades cut the tree neatly and efficiently. After cutting the top of the tree stay still vertical position if wanted and it is easy to move to the loading area or fell tree direct to the trailer.

Base machines: small/medium size harvesters, small/medium size forwarders and, Tractors and forest trailers with over 6,5m (21,3 ft) crane and small excavators 3 – 6 t (6613–16075 lbs).



FEATURES

  • No hoses or electrical wires to restrict grapple rotator

  • Cutting, loading, and delimbing the tree

  • Collector boosts productivity

  •  Easy and fast connecting

  •  Guillotine and tilt-unit is possible to lock loading position

  •  Also works as a loading grapple

  •  Made with Hardox steel

jak-20x-grapple-3
jak-20x-grapple-4
jak-20x-grapple
model-20x-fitting-options

JAK-20X MULTI GRAPPLE

Agile JAK-20X collects and digs


20X is equipped with four independent jaws. It ensures a tight grip on pieces of different shapes. The grapple can hold up to 300 (79,2 gal) liters of desired material at once like firewood etc, thus its usability as a working tool is extremely efficient.


20X is suited for various timber cranes, rotators, truck hoists, small-scale forest machines, and forwarders. With the 20X grapple, you can perform versatile farm, worksite, waterfront and river, roadside and garden works that require agile and durable grapple.



FEATUERS

  • Loading firewood up to 300 litres (79,2 gal) at once

  • Loading chips, sand, stones, soil, manure, bale etc,

  • Easy remove bushes and even make small excavation works with your crane

  •  Lightweight and durable
